Product Details
Place of Origin: China
Brand Name: SMART CNC
Certification: CE ISO TUV
Model Number: 1000W
Payment & Shipping Terms
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Nude
Delivery Time: 45days
Supply Ability: 50 sets/month
Cutting Area: |
1250*2500mm |
Cooling Mode: |
Water Cooling |
Laser Power: |
1000W |
Control System: |
Cypcut Control System |
Cutting Speed: |
0-40000mm/min |
Warranty Time: |
3 Years |
Brand: |
SMART CNC |
Cutting Area: |
1250*2500mm |
Cooling Mode: |
Water Cooling |
Laser Power: |
1000W |
Control System: |
Cypcut Control System |
Cutting Speed: |
0-40000mm/min |
Warranty Time: |
3 Years |
Brand: |
SMART CNC |
This is metal tube fiber laser cutting machine
Pipe laser cutting machine with 3000mm,6000mm or 8000mm.
It can cut round,square,irregularity,rectangle metal tube
The machine can support minimum metal tube outer diameter 20x20mm, maximum outer diameter 200x200m
The fiber laser cutting machine laser source support IPG, Raycus and nLIGH, cutting head support Precitec and RayTools
The sofware used Chinese best brand which is Cypcut and CypTube
Laser power from 500 watts to 8000 watts
What is brand servo motor we used?
YASKAWA from Japan, Beckoff from Germany
Rack and pinion:Atlanta from Germany, YYC from Taiwan
Linear guide:Bosch from Germany, HIWIN from Taiwan
Reducer:Neugart from Germany, Shimpo from Japan
Water chiller:Tongfei brand
Plate and pipe fiber laser cutting machine
Sometimes,customers need to cut plate and pipe both of them,Don't worry, have plate and pipe fiber laser cutting machine
Plate sheet working area mostly 3000x1500mm,and pipe lenght can do 3000mm or 6000mm, It depend on customer
exact requiremnet.
Plate fiber laser cutting machine
This machine is hot sale in our factory, so standard working area 3000x1500mm ,4000x2000mm and 6000x2000mm
The 1000 watts and 2000 watts is much more popular in the world. This is because low power and middle power can
use Chinese brnad laser source which can do customers business as well.75% customers will choose the Raycus laser
source. But for high power have to use IPG or nLIGHT laser source.It ensure your longtime and continuous working time
per day. So the laser source is key part for complete fiber laser cutting machine.
| Fiber Laser Cutting Machine Technical Parameters | |
| Laser Type | Fiber laser |
| Laser Brand | IPG / Raycus |
| Laser Power | 500W (750W / 1000W /2000W/3000W/4000W optional) |
| Working area | 1500mmX3000mm 1300x2500mm 2000*4000mm Optional |
| Working Table | Fixed Working Table |
| Control System | PMAC full-closed loop servo control |
| Driving Mode | Double gear rack driving |
| Positioning Accuracy | 0.05mm |
| Protection System | Enclosure protection |
| Cutting Head | Precitec / Laser Mech / |
| Power Supply | AC380V ± 5% 50 / 60Hz |
| Total Power | 7KW~11KW |
| Standard Collocation |
Metal nesting software, dual-pressure gas route of 3 kind gas sources, dynamic focus, remote controller, etc. |
| Software | CutMax Laser Cutting Software or PA8000 software, Metal Nesting Software |
| Supported Format |
PLT, DXF, BMP, AI, DST, DWG, etc. |
