Product Details
Place of Origin: China
Brand Name: SMART CNC
Certification: CE ISO TUV
Model Number: WC67K-400/6000
Payment & Shipping Terms
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Nude
Delivery Time: 30 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50 set/month
Bending Width: |
6000mm |
Pressure: |
4000KN |
Motor: |
Siemens |
Valve: |
Rexroth |
Electrical: |
Siemens |
Delivery Time: |
60 Days |
Warranty Time: |
Two Years |
Servo: |
Japan |
Bending Width: |
6000mm |
Pressure: |
4000KN |
Motor: |
Siemens |
Valve: |
Rexroth |
Electrical: |
Siemens |
Delivery Time: |
60 Days |
Warranty Time: |
Two Years |
Servo: |
Japan |
400TON 6000mm Stainless Steel Hydraulic Press Brake In Steel Structure Industry
Main Features:
1. All steel welded structure, integrated treatment (vibration aging, heat treatment) heating to eliminate stress, have good rigidity and stability
2. Heat treatment of the rack, rigidity optimization verification on entire machine and the application of hydraulic compensation structure jointly ensure the bending precision of MB8 series Press Brakes.
3. Programming a product simply consists of introducing the characteristics of the material to be bent,the dimensions of the product and the necessary tooling & die.The optimizing software searches for the best bending cycle.
4. Rear block distance, upper stroke, electric adjustment, manual fine adjustment device, digital display.
5. Imports including linear transducer,pressure proportional valve and servo motor.
6. Ram stroke(Y1,Y2) and backgauge(X,R,Z) are controlled by controller automatically,high productivity.
7. Adopting Electro-hydraulic proportional servo synchronization. Optional point within stroke can be controlled.Repeat precision of Y axes: ±0.01mm, Parallism: 0.02mm. Strong ability of deviation resistance.
8. Backgauge adopts ball-bearing screw and rolling guideway,quick speed and high repeat positioning precision.X axes with resolution 0.1mm.
Standard Equipment:
1. System Intermediate Upper clamps with Anti Wedges
2. Plate Support Arms
3. Powered Depth Axis
4. Backstop
5. Light guards
6. Top and Bottom Tooling
7. Estun E21 NC control
8. Germany Bosch-Rexroth Hydraulic
9. Telemecanique/SchneiderElectrics
10. Hydraulic and Electrical overload protection
11. Squaring Arm and Front Support Arms
12. Delta inverter with ball screw and polished rod with 0.05 mm accuracy.
13. Side guard is standard meeting CE regulations.
Estun E21s NC Press Brake Control system:
1. Monochrome LCD Box Panel.
2. Integral factor programmable freely
3. Automatic positioning control
4. Spindle allowance offset
5. Internal time relay
6. Stock counter
7. Backgauge position display, resolution in 0.01mm
The best bending results You can bend longer and deeper parts with standard AC/MB7-Bend Series.
WC67Y/WC67K Series Technical Parameters
| Model |
Nominal pressure (mm) |
Worktable length (mm) |
Distance between housings (mm) |
Throat depth (mm) |
Stroke (mm) |
Max. opening height (mm) |
Power (KW) |
Dimension LxWxH (mm) |
| 30T/1600 | 300 | 1600 | 1280 | 200 | 80 | 285 | 3 | 1600x1000x1600 |
| 35T/2000 | 350 | 2000 | 1480 | 200 | 80 | 285 | 4 | 2000x1100x1800 |
| 40T/2200 | 400 | 2200 | 1850 | 230 | 100 | 320 | 5.5 | 2200x1200x1910 |
| 40T/2500 | 400 | 2500 | 1850 | 230 | 100 | 320 | 5.5 | 2500x1200x1910 |
| 50T/2500 | 500 | 2500 | 1850 | 230 | 100 | 320 | 5.5 | 2500x1200x2000 |
| 63T/2500 | 630 | 2500 | 1900 | 250 | 100 | 320 | 5.5 | 2500x1300x2210 |
| 63T/3200 | 630 | 3200 | 2500 | 250 | 100 | 320 | 5.5 | 3200x1300x2210 |
| 80T/2500 | 800 | 2500 | 1900 | 300 | 100 | 320 | 7.5 | 2500x1400x2300 |
| 80T/3200 | 800 | 3200 | 2500 | 320 | 100 | 350 | 7.5 | 3200x1500x2300 |
| 80T/4000 | 800 | 4000 | 3000 | 320 | 100 | 350 | 7.5 | 4000x1500x2400 |
| 100T/2500 | 1000 | 2500 | 1900 | 320 | 120 | 320 | 7.5 | 2500x1600x2400 |
| 100T/3200 | 1000 | 3200 | 2500 | 320 | 120 | 370 | 7.5 | 3200x1600x2600 |
| 100T/4000 | 1000 | 4000 | 3000 | 320 | 120 | 370 | 7.5 | 4000x1600x2700 |
| 125T/3200 | 1250 | 3200 | 2500 | 320 | 120 | 370 | 7.5 | 3200x1600x2600 |
| 125T/4000 | 1250 | 4000 | 3000 | 320 | 120 | 370 | 7.5 | 4000x1600x2700 |
| 160T/3200 | 1600 | 3200 | 2500 | 320 | 200 | 460 | 11 | 3200x1700x2700 |
| 160T/4000 | 1600 | 4000 | 3000 | 320 | 200 | 460 | 11 | 4000x1700x2800 |
| 160T/5000 | 1600 | 5000 | 4000 | 320 | 200 | 460 | 11 | 5000x1900x3100 |
| 160T/6000 | 1600 | 6000 | 4940 | 320 | 200 | 460 | 11 | 6000x1900x3200 |
| 200T/3200 | 2000 | 3200 | 2500 | 320 | 200 | 460 | 11 | 3200x1950x2800 |
| 200T/4000 | 2000 | 4000 | 3000 | 320 | 200 | 460 | 11 | 4000x1950x2800 |
| 200T/5000 | 2000 | 5000 | 4000 | 320 | 200 | 460 | 11 | 5000x1950x3000 |
| 200T/6000 | 2000 | 6000 | 5000 | 320 | 200 | 460 | 11 | 6000x1950x3300 |
| 250T/3200 | 2500 | 3200 | 2500 | 400 | 250 | 590 | 18.5 | 3200x2000x3200 |
| 250T/4000 | 2500 | 4000 | 3000 | 400 | 250 | 590 | 18.5 | 4000x2000x3400 |
| 250T/5000 | 2500 | 5000 | 4000 | 400 | 250 | 590 | 18.5 | 5000x2000x3400 |
| 250T/6000 | 2500 | 6000 | 5000 | 400 | 250 | 590 | 18.5 | 6000x2000x3400 |
| 300T/3200 | 3000 | 3200 | 2530 | 400 | 250 | 590 | 22 | 3200x2000x3450 |
| 300T/4000 | 3000 | 4000 | 3000 | 400 | 250 | 590 | 22 | 4000x2000x3450 |
| 300T/5000 | 3000 | 5000 | 4000 | 400 | 250 | 590 | 22 | 5000x2000x3450 |
| 300T/6000 | 3000 | 6000 | 5000 | 400 | 250 | 590 | 22 | 6000x2000x3450 |
| 400T/4000 | 4000 | 4000 | 3000 | 400 | 250 | 590 | 30 | 4000x2180x3400 |
| 400T/5000 | 4000 | 5000 | 4000 | 400 | 250 | 590 | 30 | 5000x2180x3500 |
| 400T/6000 | 4000 | 6000 | 5000 | 400 | 250 | 590 | 30 | 6000x2180x3800 |
| 500T/5000 | 5000 | 5000 | 4000 | 400 | 250 | 590 | 45 | 5050x3500x3700 |
| 500T/6000 | 5000 | 6000 | 5000 | 400 | 320 | 590 | 45 | 6050x3500x3700 |
| 600T/4000 | 6000 | 4000 | 3000 | 400 | 320 | 590 | 55 | 4050x4500x3700 |
| 600T/6000 | 6000 | 6000 | 5000 | 400 | 320 | 590 | 55 | 6050x4500x3700 |
| 800T/6000 | 8000 | 6000 | 5000 | 400 | 320 | 590 | 55 | 6300x4500x6000 |
Note: No notice if any changes of the above statistics made.
