Product Details
Place of Origin: China
Brand Name: SMART CNC
Certification: CE ISO TUV
Model Number: WC67K-500/6000
Payment & Shipping Terms
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Nude
Delivery Time: 30 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50 set/month
Bending Width: |
5000mm |
Pressure: |
5000KN |
Motor: |
Siemens |
Valve: |
Rexroth |
Electrical: |
Schneider |
Delivery Time: |
60 Days |
Warranty Time: |
Two Years |
Servo: |
Japan |
Bending Width: |
5000mm |
Pressure: |
5000KN |
Motor: |
Siemens |
Valve: |
Rexroth |
Electrical: |
Schneider |
Delivery Time: |
60 Days |
Warranty Time: |
Two Years |
Servo: |
Japan |
500TON 5000mm Stainless Steel Hydraulic Press Brake In Steel Structure Industry
Main Features:
» The machine frame is steel-welded construction, vibration to eliminate stress, with high strength and good rigidity.
» Mechanical stop and steel torsion bar to maintain synchronization and high precision.
» Inch, single mode being designed for the machine and reversing and maintain time can be controlled by the time relays.
» Safe fence and electric inter locker have been designed for the machine to ensure the operation safety.
» The ram adopts hydraulic top-drive with two good quality cylinders, working smoothly and stable.
» The segmented punches of different length are designed which can be combined into a certain length according to the processing demand to meet the different requirement of special workpieces.
» Back gauge is driven by guide way, quick, convenient and accurate.
» The machine can be adopted with normal clamp devices or quick clamp as an option according to the customer's requirement to decrease the labors' work and increase work efficiency.
Standard Equipment:
1. System Intermediate Upper clamps with Anti Wedges
2. Plate Support Arms
3. Powered Depth Axis
4. Backstop
5. Light guards
6. Top and Bottom Tooling
7. Estun E21 NC control
8. Germany Bosch-Rexroth Hydraulic
9. Telemecanique/SchneiderElectrics
10. Hydraulic and Electrical overload protection
11. Squaring Arm and Front Support Arms
12. Delta inverter with ball screw and polished rod with 0.05 mm accuracy.
13. Side guard is standard meeting CE regulations.
Estun E21s NC Press Brake Control system:
1. Monochrome LCD Box Panel.
2. Integral factor programmable freely
3. Automatic positioning control
4. Spindle allowance offset
5. Internal time relay
6. Stock counter
7. Backgauge position display, resolution in 0.01mm
The best bending results You can bend longer and deeper parts with standard AC/MB7-Bend Series.
WC67Y/WC67K Series Technical Parameters
| Model |
Nominal pressure (mm) |
Worktable length (mm) |
Distance between housings (mm) |
Throat depth (mm) |
Stroke (mm) |
Max. opening height (mm) |
Power (KW) |
Dimension LxWxH (mm) |
| 30T/1600 | 300 | 1600 | 1280 | 200 | 80 | 285 | 3 | 1600x1000x1600 |
| 35T/2000 | 350 | 2000 | 1480 | 200 | 80 | 285 | 4 | 2000x1100x1800 |
| 40T/2200 | 400 | 2200 | 1850 | 230 | 100 | 320 | 5.5 | 2200x1200x1910 |
| 40T/2500 | 400 | 2500 | 1850 | 230 | 100 | 320 | 5.5 | 2500x1200x1910 |
| 50T/2500 | 500 | 2500 | 1850 | 230 | 100 | 320 | 5.5 | 2500x1200x2000 |
| 63T/2500 | 630 | 2500 | 1900 | 250 | 100 | 320 | 5.5 | 2500x1300x2210 |
| 63T/3200 | 630 | 3200 | 2500 | 250 | 100 | 320 | 5.5 | 3200x1300x2210 |
| 80T/2500 | 800 | 2500 | 1900 | 300 | 100 | 320 | 7.5 | 2500x1400x2300 |
| 80T/3200 | 800 | 3200 | 2500 | 320 | 100 | 350 | 7.5 | 3200x1500x2300 |
| 80T/4000 | 800 | 4000 | 3000 | 320 | 100 | 350 | 7.5 | 4000x1500x2400 |
| 100T/2500 | 1000 | 2500 | 1900 | 320 | 120 | 320 | 7.5 | 2500x1600x2400 |
| 100T/3200 | 1000 | 3200 | 2500 | 320 | 120 | 370 | 7.5 | 3200x1600x2600 |
| 100T/4000 | 1000 | 4000 | 3000 | 320 | 120 | 370 | 7.5 | 4000x1600x2700 |
| 125T/3200 | 1250 | 3200 | 2500 | 320 | 120 | 370 | 7.5 | 3200x1600x2600 |
| 125T/4000 | 1250 | 4000 | 3000 | 320 | 120 | 370 | 7.5 | 4000x1600x2700 |
| 160T/3200 | 1600 | 3200 | 2500 | 320 | 200 | 460 | 11 | 3200x1700x2700 |
| 160T/4000 | 1600 | 4000 | 3000 | 320 | 200 | 460 | 11 | 4000x1700x2800 |
| 160T/5000 | 1600 | 5000 | 4000 | 320 | 200 | 460 | 11 | 5000x1900x3100 |
| 160T/6000 | 1600 | 6000 | 4940 | 320 | 200 | 460 | 11 | 6000x1900x3200 |
| 200T/3200 | 2000 | 3200 | 2500 | 320 | 200 | 460 | 11 | 3200x1950x2800 |
| 200T/4000 | 2000 | 4000 | 3000 | 320 | 200 | 460 | 11 | 4000x1950x2800 |
| 200T/5000 | 2000 | 5000 | 4000 | 320 | 200 | 460 | 11 | 5000x1950x3000 |
| 200T/6000 | 2000 | 6000 | 5000 | 320 | 200 | 460 | 11 | 6000x1950x3300 |
| 250T/3200 | 2500 | 3200 | 2500 | 400 | 250 | 590 | 18.5 | 3200x2000x3200 |
| 250T/4000 | 2500 | 4000 | 3000 | 400 | 250 | 590 | 18.5 | 4000x2000x3400 |
| 250T/5000 | 2500 | 5000 | 4000 | 400 | 250 | 590 | 18.5 | 5000x2000x3400 |
| 250T/6000 | 2500 | 6000 | 5000 | 400 | 250 | 590 | 18.5 | 6000x2000x3400 |
| 300T/3200 | 3000 | 3200 | 2530 | 400 | 250 | 590 | 22 | 3200x2000x3450 |
| 300T/4000 | 3000 | 4000 | 3000 | 400 | 250 | 590 | 22 | 4000x2000x3450 |
| 300T/5000 | 3000 | 5000 | 4000 | 400 | 250 | 590 | 22 | 5000x2000x3450 |
| 300T/6000 | 3000 | 6000 | 5000 | 400 | 250 | 590 | 22 | 6000x2000x3450 |
| 400T/4000 | 4000 | 4000 | 3000 | 400 | 250 | 590 | 30 | 4000x2180x3400 |
| 400T/5000 | 4000 | 5000 | 4000 | 400 | 250 | 590 | 30 | 5000x2180x3500 |
| 400T/6000 | 4000 | 6000 | 5000 | 400 | 250 | 590 | 30 | 6000x2180x3800 |
| 500T/5000 | 5000 | 5000 | 4000 | 400 | 250 | 590 | 45 | 5050x3500x3700 |
| 500T/6000 | 5000 | 6000 | 5000 | 400 | 320 | 590 | 45 | 6050x3500x3700 |
| 600T/4000 | 6000 | 4000 | 3000 | 400 | 320 | 590 | 55 | 4050x4500x3700 |
| 600T/6000 | 6000 | 6000 | 5000 | 400 | 320 | 590 | 55 | 6050x4500x3700 |
| 800T/6000 | 8000 | 6000 | 5000 | 400 | 320 | 590 | 55 | 6300x4500x6000 |
Note: No notice if any changes of the above statistics made.
